Canor Hyperion P1 Rør Forforstærker
74.650,00 DKK
Dette produkt kan købes ved personlig henvendelse!
Hyperion P1 is a brand new vacuum tube preamplifier of pure A-class with zero feedback designed and produced by CANOR.
It is considered a reference preamplifier of the CANOR brand.
Product Features
- the attenuator is located in a special aluminium box (10 mm thick walls) which provides perfect shielding and thanks to the special design it also absorbs the vibrations.
- the Hyperion P1 is a Class-A preamplifier and was designed to avoid ANY global feedback.
- the attenuator, as well as the electronic part, are installed on anti-vibration pads (columns) which contributes to the overall elimination of vibrations.
- the analog part is separated from the power part by a solid aluminum wall (10 mm thick) which contributes to the elimination of interference.
- the attenuator control is galvanically separated via optical drivers.
Technical specifications:
| Gain (XLR OUT) | 11 dB |
| Output Impedance | < 150 Ω |
| Frequency response | 10 - 80 000 Hz ± 0,1 dB |
| Input impedance | 30 kΩ |
| Inputs | 4 x XLR, 5 x RCA (One pair selectable as FIX.OUT) |
| Outputs | 2 x XLR, 1 x RCA |
| Total Harmonic Distortion | < 0,005% (1 kHz, 2 V RMS) XLR < 0,3 % (1 kHz, 49 V RMS) XLR |
| Channel separation | > 110 dB |
| Signal-to-noise ratio | > 115 dB (20 Hz - 80 kHz) |
| Tube complement | 4x 6922, 2x 6H30PI |
| Power | 230 V / 50-60 Hz / 180 VA |
| Dimensions (w x h x d) | 450 x 190 x 465 mm |
| Weight (net) | 29 kg |
