Psvane 5U4G Rør

Pris per stk.

5U4G is glass- shell eight- feet directly heated full-wave rectifier tube，5U4G is very similar with 274B  and 5Z3P, which can be replaced by each other.

Heater
Uf………………5V
If…………… 3A

Maximum Rating
anode inverse peak voltage……………1550V
anode peak current        ………675mA

Recommend operating condition

Anode supply voltage             2×500V
Each arm impedance               75Ω
load impedance                   2000Ω
Filter capacitor                 40μF
Rectifier current                ≧230mA
